Sabra Metals stands out as a leading manufacturer and supplier based in Amman, Jordan, with a focus on high-quality Titanium Grade 7 Forgings. These products are essential for industries that need top-notch corrosion resistance and mechanical performance. Renowned for their precision engineering and commitment to international quality standards, Sabra Metals provides titanium forgings that meet the toughest industrial demands. Their Titanium Grade 7 Forgings are known for their remarkable durability and chemical stability, making them perfect for critical applications in tough environments. With cutting-edge production capabilities and a strong emphasis on customer satisfaction, Sabra Metals has earned a reputation as a reliable source of titanium solutions, both regionally and globally.
Titanium Grade 7 Forgings are made from commercially pure titanium, with a carefully controlled addition of palladium (0.12–0.25%) to boost their resistance to corrosive environments, especially in reducing and mildly oxidizing conditions. These forgings boast excellent mechanical properties, including impressive tensile strength, high ductility, impact toughness, and outstanding weldability. They effectively resist pitting, crevice corrosion, and stress-corrosion cracking, all while maintaining stability across a broad temperature range. When compared to other titanium grades, Grade 7 shines with its exceptional corrosion performance and dependable mechanical strength, making it ideal for demanding industrial applications.
| Specifications | ASTM B381, ASME SB381 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | N | O | H | Ti | Fe | Al | Pd |
| Titanium Gr 7 | 08 max | 03 max | 25 max | 015 max | Bal | 0.30 max | – | .12 – .25 |
| 0.2% Proof Stress MPa | Tensile Strength MPa | Elongation % |
| 275-475 | 345 | 20 |
| STANDARD | WERKSTOFF NR. | UNS |
| Titanium Gr. 7 | 3.7235 | R52400 |
Yes, Titanium Grade 7 (Ti-0.2Pd) is highly corrosion-resistant, especially in harsh environments like seawater and acidic conditions, due to the addition of palladium, enhancing its ability to resist corrosion.
Titanium Grade 7 forgings are commonly used in industries like aerospace, chemical processing, marine, medical, and power generation due to their exceptional corrosion resistance, strength, and biocompatibility in challenging environments.
Titanium Grade 7 forgings are available in various sizes and shapes, including bars, billets, rings, discs, and custom configurations, typically ranging from small to large diameters for different industrial applications.
You’ll find Titanium Grade 7 Forgings widely utilized in industries that require high-performance, corrosion-resistant materials. They’re commonly found in chemical processing equipment, heat exchangers, pressure vessels, and marine components that face seawater or harsh chemical environments. Their ability to withstand reducing acids makes them perfect for reactors, piping systems, and storage tanks that handle corrosive chemicals. In the power generation sector, they’re used for condenser components and cooling systems. Plus, their impressive strength-to-weight ratio and durability make them a great fit for aerospace, medical, and environmental applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Sabra Metals is a leading manufacturer, supplier, and exporter of high-quality bars, rods, and forgings, catering to various industries in Amman, Jordan
