Sabra Metals, based in Amman, Jordan, has built a solid reputation as a reliable manufacturer and supplier of top-notch aluminum products, particularly bars and rods tailored for various industrial uses. They cater to sectors like marine, automotive, construction, and transportation, offering aluminum solutions that are both durable and resistant to corrosion. Thanks to their state-of-the-art production facilities and strict quality control measures, Sabra Metals guarantees that each bar and rod adheres to international standards. Their deep knowledge in materials engineering enables them to produce dependable, high-performance components, making them a go-to partner for clients in search of premium Aluminium 5082 bars and rods.
Aluminium 5082 is a non-heat-treatable alloy mainly made up of aluminum and magnesium (4.0–4.9%), along with trace amounts of manganese (0.4–1.0%) and chromium (0.05–0.25%). This composition gives it remarkable corrosion resistance, especially in marine and industrial settings. In terms of mechanical properties, it boasts a tensile strength of about 230–290 MPa, a yield strength of around 125–270 MPa, and an elongation rate of 12–25%, depending on the temper. The alloy is known for its good formability, moderate hardness, and excellent weldability, making Aluminium 5082 bars and rods perfect for applications that demand lightweight, strong, and durable components. s composition consisting of 4.0-4.9% Mg, 0.1-0.2% Mn, 0.05-0.25% Si, along with trace elements of Cu, Fe, and Cr. It has good corrosion resistance in a marine environment, and the alloy has excellent weldability and formability. Its mechanical properties contain tensile strength between 270 and 340 MPa; yield strength can reach up to 230 MPa, elongation of nearly 12-15%. Widespread utilization is found where strength and the resistance to seawater are also required.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| GRADE | Al | Cr | Cu | Fe | Mg | Mn | Si | Ti | Zn | Residuals |
| 5082 | 95.2 to 98.3% | 0.25% max | 0.1% max | 0.5% max | 0.6 to 1.2% | 0.4% to 1.0% | 0.7 to 1.3% | 0.1% max | 0.2% max | 0.15% max |
| Density | Melting Point | Modulus of Elasticity | Electrical Resistivity | Thermal Conductivity | Thermal Expansion | Specific Heat |
| Value | 2700 kg/m3 | 555°C | 70 GPa | 0.038×10-6 Ω.m | 180 W/m.K | 24×10-6 /K |
| European Standard | OLD | WNr | UNS | ISO | USA (AA) | GERMANY (DIN) |
| AW-AlMg4,5 | AG4,5 | 3.3345 | A95082 | AlMg4,5 | 5082 | AlMg4,5 |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Maintain Aluminum 5082 bars by regularly cleaning with mild soap and water to prevent dirt buildup. Avoid harsh chemicals, use non-abrasive tools, and protect against corrosion by storing in dry conditions.
Yes, Aluminium 5082 bars are recyclable. Like most aluminum alloys, they can be melted down and reused without significant loss of properties, making them an environmentally sustainable material.
Yes, Aluminium 5082 rods can be customized in size and length. Manufacturers often offer custom dimensions to meet specific requirements for industrial, construction, or engineering applications.
These bars and rods are extensively utilized in marine and shipbuilding projects for structural elements, hull reinforcements, and offshore platforms, thanks to their impressive resistance to seawater corrosion. They also find their place in the automotive and transportation sectors for chassis components, frames, and load-bearing parts where strength and durability are crucial. Furthermore, you’ll see these bars and rods in construction, industrial equipment, and machinery that face tough environmental conditions. Their blend of corrosion resistance, high strength, and formability makes Aluminium 5082 bars and rods both versatile and dependable for demanding applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
