Sabra Metals, located in Amman, Jordan, stands out as a top manufacturer and supplier of premium aluminum products, focusing on bars and rods tailored for industrial use. They cater to various sectors, including marine, automotive, transportation, and construction, delivering aluminum solutions that are both durable and resistant to corrosion. With state-of-the-art production facilities and rigorous quality control measures, Sabra Metals guarantees that each bar and rod adheres to international standards. Their deep knowledge in materials engineering enables them to produce reliable, high-performance components, making Sabra Metals a go-to partner for clients in search of top-notch Aluminium 5086 bars and rods.
Aluminium 5086 is a non-heat-treatable alloy mainly made up of aluminum and magnesium (4.0–4.9%), along with trace amounts of manganese (0.2–0.5%) and chromium (0.05–0.25%). This composition gives it remarkable corrosion resistance, especially in seawater and tough environments. Its mechanical properties boast a tensile strength of about 240–310 MPa, yield strength of around 125–270 MPa, and elongation ranging from 12–25%, depending on the temper. The alloy also offers good formability, moderate hardness, and excellent weldability, making Aluminium 5086 bars and rods perfect for applications that demand lightweight, strong, and durable components.
| Aluminium Alloy | ASTM B211, B211, B565, B316 5082, AMS 4121 |
| Standard | ASTM, ASME, AMS, GB/T, JIS |
| Aluminium Round Bar Temper | O, H12, H14, H16, H18, H22, H24, H26, H32, H112 |
| Aluminium Bar Form | Aluminium Round, Hex, Flat, Half Round, Oval, Rectangular in Black & Bright Finish |
| Aluminium Round Bar Diameter | 0.1-600mm,etc |
| Aluminium Hexagonal Bar | 0.1-600mm,etc |
| Aluminium Angle Bar Size | 0.5mm*40mm*40mm-20mm*400mm*400mm |
| Aluminium Flat Bar Thickness | 0.1-600mm,etc |
| Aluminium Flat Bar Size | 1-2500mm, etc |
| Aluminium Round Bar Length | 1-12m, Random, Fix & Cut Length or as per clients’ requirement |
| Aluminium Bar | Bright, Polish & Black |
| GRADE | Si | Ir | Cu | Mn | Mg | Cr | Zn | Ti | Others, each | Others, total | Al |
| 5086 | 0.4 | 0.5 | 0.1 | 0.20-0.70 | 3.5-4.5 | 0.05-0.25 | 0.25 | 0.15 | 0.05 | 0.15 | Balance |
| Properties | Proof Stress | Tensile Strength | Hardness Brinell | Elongation |
| Metric | 125 Min MPa | 275 – 350 MPa | 75 HB | 12 Min % |
| European Standard | OLD | WNr | UNS | ISO | USA (AA) | GERMANY (DIN) |
| AW-AlMg4 | AG4MC | 3.3545 | A95086 | AlMg4 | 5086 | AlMg4Mn |
| Size in mm | Average Weight | |
| KG/MTR | KG/FT | |
| 10 | 0.62 | 0.18 |
| 12 | 0.90 | 0.30 |
| 14 | 1.20 | 0.40 |
| 16 | 1.60 | 0.50 |
| 18 | 2.00 | 0.60 |
| 20 | 2.50 | 0.80 |
| 22 | 3.00 | 0.90 |
| 24 | 3.56 | 1.08 |
| 25 | 3.90 | 1.20 |
| 28 | 4.80 | 1.50 |
| 30 | 5.55 | 1.69 |
| 32 | 6.30 | 1.90 |
| 34 | 7.14 | 2.18 |
| 36 | 8.00 | 2.44 |
| 40 | 9.90 | 3.00 |
| 45 | 12.49 | 3.81 |
| 50 | 15.40 | 4.70 |
| 56 | 19.34 | 5.89 |
| 60 | 22.20 | 6.80 |
| 63 | 24.47 | 7.46 |
| 63.5 | 24.86 | 7.58 |
| 65 | 26.05 | 7.94 |
| 70 | 30.20 | 9.20 |
| 73 | 32.86 | 10.00 |
| 75 | 34.72 | 10.58 |
| 78 | 37.51 | 11.43 |
| 80 | 39.50 | 12.00 |
| 83 | 42.47 | 12.95 |
| 85 | 44.55 | 13.58 |
| 90 | 50.00 | 15.20 |
| 92 | 52.19 | 15.91 |
| 93 | 53.39 | 16.27 |
| 95 | 55.65 | 16.95 |
| 100 | 61.66 | 18.79 |
| 105 | 67.98 | 20.72 |
| 110 | 74.60 | 22.74 |
| 115 | 81.64 | 24.88 |
| 125 | 96.34 | 29.36 |
Yes, Aluminium 5086 bars are fully recyclable. Aluminium is a sustainable material that can be recycled repeatedly without losing its properties, making it an environmentally friendly option for various applications.
Yes, Aluminium 5086 bars and rods can be used for potable water applications due to their corrosion resistance and durability, making them suitable for marine environments and water treatment systems.
When installing Aluminium 5086 bars and rods, consider factors such as proper handling to avoid damage, ensuring compatibility with other materials, and protecting against corrosion by using appropriate coatings or finishes.
These bars and rods find extensive use in marine settings, such as ship hulls, decks, offshore structures, and marine frameworks, thanks to their outstanding resistance to saltwater corrosion. They’re also utilized in the automotive and transportation sectors for structural parts, chassis components, and load-bearing applications where strength and reliability are paramount. Furthermore, Aluminium 5086 bars and rods are employed in industrial equipment, heavy machinery, and construction projects that face harsh conditions. Their blend of corrosion resistance, high strength, and versatility makes them a dependable choice for demanding applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
