Based in Amman, Jordan, Sabra Metals has built a solid reputation as a reliable manufacturer and supplier of high-quality Monel Rectangular Bars. These bars are specifically designed for applications that demand exceptional corrosion resistance and mechanical strength. Crafted from nickel-copper alloys, they excel in challenging environments like marine, chemical, and high-pressure settings. Sabra Metals takes pride in maintaining strict standards for chemical composition, dimensional accuracy, and surface finish, ensuring they meet international quality benchmarks. With state-of-the-art manufacturing facilities and dependable supply capabilities, the company caters to industries such as marine engineering, oil and gas, chemical processing, power generation, and heavy engineering around the globe.
Monel Rectangular Bars are mainly made up of nickel (about 63–70%) and copper, with small amounts of iron, manganese, and other elements varying by grade. This unique alloy composition grants them remarkable corrosion resistance, especially in seawater and acidic conditions. On the mechanical side, Monel boasts high tensile strength, good yield strength, and impressive toughness. It retains stable mechanical properties across a broad temperature range and shows strong resistance to stress corrosion cracking.
| Monel Rectangular Bar Standard | ASTM B164, ASTM B865, AMS 5513, AMS 5511, AMS 5647 |
|---|---|
| Monel Rectangular Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
| Alloy Rectangular Bars Section | 3.0 to 12.0mm thickness |
| Monel Rectangular Size | 33 x 30mm to 295 x 1066mm |
| JIS NW Rectangular-Bar Surface | Bright, Hot Rolled Pickled, Cold Drawn, Sand Blasting Finished, Polished, Hairline |
| Rolled Monel Rectangular Bars Condition | Hardened & tempered, annealed |
| Type Cold Rolled Retangular Bar Technique | Alloy Hot Rolled, Cold Drawn, Cold Rolled, Forged Round Bar, Rod |
| Monel Alloy Rod Processing | Bar cutting to 650mm |
| Element | Max | Min |
| Ni | – | 63.0 |
| Fe | 1.0 – 2.5 | – |
| C | 0.3 | – |
| Mn | 2.0 | – |
| Si | 0.5 | – |
| Cu | 28.0 – 34.0 | – |
| Al | 0.50 | – |
| S | 0.02 | – |
| Element | Monel |
| Density | 8.8 g/cm3 |
| Melting Point | 1350 °C (2460 °F) |
| Tensile Strength | Psi – 80,000 , MPa – 550 |
| Yield Strength (0.2%Offset) | Psi – 35,000 , MPa – 240 |
| Elongation | 40 % |
Yes, we provide bars and rods in standard and customized dimensions and polishes to meet your specific project requirements. For more details mail us on sales@sabrametals.com
Monel Rectangular Bars are used in the oil and gas industry for manufacturing components such as piping, valves, and heat exchangers, where resistance to corrosion and high pressure is critical.
Monel Rectangular Bars maintain excellent strength and stability in high-temperature environments, making them suitable for use in heat exchangers, reactors, and other high-heat industrial applications.
Monel Rectangular Bars find their place in a variety of applications where both strength and corrosion resistance are essential. They are commonly used for structural supports, base plates, brackets, shafts, and other fabricated components. These bars are particularly valuable in marine structures, offshore platforms, oil and gas processing equipment, chemical plants, and power generation facilities. Additionally, Monel rectangular bars are ideal for heat exchangers, pump components, and pressure equipment that come into contact with seawater, acids, and high-pressure conditions, ensuring a long service life and dependable performance.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
