Based in Amman, Jordan, Sabra Metals is a trusted name in the manufacturing and supply of Stainless Steel 316 Forgings, designed for industrial applications that demand corrosion resistance and high performance. These forgings are crafted from molybdenum-bearing austenitic stainless steel, which provides exceptional resistance to chlorides and harsh chemicals. Sabra Metals adheres to rigorous forging practices, precise heat treatment, and international quality standards to guarantee outstanding mechanical strength, a refined grain structure, and a long service life. The company caters to demanding sectors throughout the Middle East and beyond.
Stainless Steel 316 Forgings are made up of chromium (16–18%), nickel (10–14%), and molybdenum (2–3%), which greatly improve their resistance to pitting and crevice corrosion. This alloy is known for its excellent toughness, high ductility, and good weldability. In terms of mechanical properties, SS 316 strikes a balance between tensile and yield strength, providing reliable impact resistance even at low and moderately high temperatures. It maintains its mechanical stability under pressure and in corrosive environments, making it a great choice for critical forged components.
| Specifications | ASTM A182, ASME SA182 |
|---|---|
| Standard | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| SS 316 | 0.08 max | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 16.00 – 18.00 | 2.00 – 3.00 | 11.00 – 14.00 | 67.845 min |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1399 °C (2550 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 316 | 1.4401 / 1.4436 | S31600 | SUS 316 | 316S31 / 316S33 | – | Z7CND17‐11‐02 | X5CrNiMo17-12-2 / X3CrNiMo17-13-3 |
Yes, Stainless Steel 316 forgings can be shaped into custom forms using precision forging techniques, allowing for a wide range of applications in various industries, including marine and chemical sectors.
The ideal temperature range for forging Stainless Steel 316 is between 2100°F to 2300°F (1149°C to 1260°C), ensuring optimal ductility and minimizing the risk of cracking.
The forging process for Stainless Steel 316 typically takes from a few minutes to several hours, depending on the part's complexity, size, and required finishing.
Stainless Steel 316 Forgings find their place in a variety of applications that require top-notch corrosion resistance and mechanical reliability. Common uses include valve bodies, pump components, flanges, fittings, and parts for pressure vessels. They are widely utilized in industries such as chemical processing, oil and gas, marine, pharmaceuticals, and food processing. Thanks to their resistance to chlorides and aggressive chemicals, SS 316 forgings are particularly well-suited for offshore structures, desalination plants, and heat exchanger components that face tough operating conditions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
