Based in Amman, Jordan, Sabra Metals is a reliable manufacturer and supplier known for its top-notch Stainless Steel 347H Forgings, designed for high-temperature and pressure-critical applications. These forgings are crafted from niobium-stabilized austenitic stainless steel with a higher carbon content, ensuring they deliver exceptional strength and outstanding resistance to intergranular corrosion, even at elevated temperatures. Sabra Metals maintains strict oversight of its forging processes, chemical makeup, and dimensional precision to comply with international standards. With state-of-the-art manufacturing facilities and thorough inspection protocols, the company caters to industries like petrochemical, power generation, oil and gas, and heavy engineering around the globe.
Stainless Steel 347H Forgings are composed of chromium (17–19%), nickel (9–13%), niobium stabilization, and a higher carbon content that boosts high-temperature strength. This unique blend helps prevent carbide precipitation and enhances creep resistance during extended heat exposure. On the mechanical side, SS 347H boasts higher tensile strength, impressive toughness, and robust resistance to thermal fatigue. The forging process refines the grain structure, leading to better pressure resistance, structural integrity, and long-lasting mechanical stability, even under extreme thermal and mechanical conditions.
| Standard | ASTM A182, ASME SA182 |
| Specification | DIN, ASTM, BS and all International Standards |
| Flat bar blocks | up to 27″ width and 15,000 lbs. |
| Cylinders and sleeves | up to 50″ maximum O.D. and 65″ maximum length |
| Discs and hubs | up to 50″ diameter and 20,000 lbs. |
| Rolled, hand forged or mandrel forged rings | up to 84″ maximum O.D. and 40″ maximum length |
| Rounds, shafts and step shafts | up to 144″ maximum length and 20,000 lbs. |
| Forging Types | Impression Die Forging, Open Die Forging, Seamless Rolled Forging, Hot Forging, Cold Forging, Open die hammer forging, Impression die drop forging, Closed Die Forging, Press Forging, Upset Forging, Compression Forging, Swaging, Rotary Forging, Roll forging. |
| Grade | C | Mn | Si | P | S | Cr | N | Ni | Ti | SS 347H | 0.04 – 0.10 | 2.0 max | 1.0 max | 0.045 max | 0.030 max | 17.00 – 19.00 | 0.10 max | 9.00 – 12.00 | 4(C+N) – 0.70 max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1457 °C (2650 °F) | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 35 % |
Yes, Stainless Steel 347H forgings can be used for potable water applications, offering excellent corrosion resistance and durability, particularly in high-temperature systems or environments with varying water quality.
Yes, Stainless Steel 347H forgings are highly suitable for high-temperature applications due to their niobium stabilization, which enhances resistance to oxidation, thermal stress, and intergranular corrosion at elevated temperatures.
Stainless Steel 347H Forgings find their place in a variety of applications that demand high temperatures, pressure, and resistance to corrosive environments. Common uses include valves, flanges, fittings, pressure vessel components, pump parts, and heat exchanger equipment. They are heavily utilized in petrochemical plants, oil and gas processing facilities, power generation plants, and industrial furnace systems. Additionally, SS 347H forgings are ideal for high-temperature piping systems and critical components where intergranular corrosion resistance and mechanical reliability are paramount.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
