Sabra Metals, a trusted manufacturer and supplier based in the heart of Amman, Jordan, proudly offers Stainless Steel 317L Rectangular Bars for demanding industrial projects. We understand that the success of your work depends on the quality and reliability of your materials. That’s why our 317L bars are produced to the highest standards, providing exceptional resistance to harsh environments. We are committed to supplying the regional market with superior products that ensure longevity and performance in even the most challenging applications, backed by our local expertise and dedication to customer satisfaction.
The strength of 317L lies in its enhanced alloy composition, which includes higher levels of molybdenum, chromium, and nickel compared to common 304 or 316 grades. This specific chemistry gives it outstanding resistance to corrosive attacks, particularly from acids like sulfuric acid and chlorides that can cause pitting. Its low carbon content makes it ideal for welding, preventing harmful carbide precipitation. This combination results in a material with excellent tensile strength and durability, making it a robust choice for components that must withstand significant stress and aggressive chemical exposure.
Standard : 317L / 1.4438
Range : 3.17mm to 350mm dia
Designation : ASTM A276, ASME SA276
Finish : Bright, Black, Polish
Thickness: 4.0mm – 100mm
Type: Bar, Bright Bar, Black Bars, Hex Bar, Square Bar, Rods, Polish Bar, Forged Bar, Round Bar
Length : Random, Fix & Cut Length
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N |
| 317L | 0.035 max | 2 max | 1 max | 0.040 max | 0.03 max | 18 – 20 | 3 – 4 | 11 – 15 | – |
| Density | 8.0 g/cm3 |
| Melting Point | 1454 °C (2650 °F) |
| Tensile Strength | Psi – 75000 , MPa – 515 |
| Yield Strength (0.2%Offset) | Psi – 30000 , MPa – 205 |
| Elongation | 35 % |
| Standard | SS 317L |
| UNS | S31703 |
| WERKSTOFF NR. / DIN | 1.4438 |
Choose Stainless Steel 317L Rectangular Bars based on the level of corrosion resistance needed for your application and the material’s strength requirements. Consider factors like temperature, pressure, and the potential for exposure to harsh chemicals or marine environments.
Stainless Steel 317L Rectangular Bars generally do not require additional corrosion protection coatings due to their inherent resistance to corrosion, especially in acidic and chloride environments. However, in highly aggressive conditions, coatings may be considered for extra protection.
When selecting Stainless Steel 317L Rectangular Bars, consider factors like corrosion resistance in aggressive environments and required mechanical properties such as strength and weldability. Also, evaluate the specific application conditions, including temperature and chemical exposure.
Due to its superior properties, Stainless Steel 317L Rectangular Bars are indispensable in industries where failure is not an option. You will often find them forming the structural backbone of chemical processing equipment, pollution control scrubbers, and components within pharmaceutical and food processing plants. Their exceptional performance in high-temperature and saline environments also makes them a preferred material for heat exchangers, marine applications, and architectural elements in coastal areas. Essentially, wherever severe corrosion is a primary concern, 317L provides the reliable, long-term solution that engineers and fabricators depend on.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
