Sabra Metals is a reliable manufacturer and supplier in Amman, Jordan, offering high‑quality stainless steel forged bars and rods for demanding industrial and structural applications. The company focuses on robust, close‑tolerance products that deliver consistent strength, toughness, and corrosion resistance for machining, fabrication, and heavy‑duty service conditions. With flexible size ranges and responsive service, Sabra Metals supports OEMs, fabricators, and project contractors with forged bars and rods tailored to international standards and diverse operating environments.
Stainless steel forged bars and rods are commonly produced in grades such as 304, 316, 310, 321, and 904L, all based on iron with chromium typically around 16–20%, nickel roughly 8–25%, and molybdenum up to about 2–3% in moly‑bearing grades like 316 and 904L. Forging refines the grain structure and improves directional strength, resulting in tensile strengths typically above 515 MPa, yield strengths above about 205 MPa, and good impact toughness, with hardness and elongation depending on specific grade and condition but generally suitable for high‑stress, fatigue‑prone applications.
Standards : ASTM A276, ASTM A484, AISI
Grade : 201, 202, 301, 302, 303, 304, 304H, 304L, 316, 316H, 316L, 309, 309S, 310, 310S, 316Ti, 317, 317L, 347, 321, 321H, 410, 416, 420, 430, 430F, 431, 440C, 630, 17-4PH, F51
Range : from 2.00mm to 6.35mm (0.078″ to 0.25″)dia.
Tolerance : DIN 671, ASTM A484 & as per customer’s specific requirement.
Finish : Cold drawn, Centreless Ground, Polished
| Grade | Su | C | Si | P | Cr | Ni | M | Mo | Other |
|---|---|---|---|---|---|---|---|---|---|
| 316 | 0.030 max | 0.08 max | 0.75 max | 0.045 max | 16.0-18.0 | 10.0 14.0 | 2.00 max | 2.0 3.0 | – |
| 317L | 0.030 max | 0.035 max | 0.75 max | 0.045 max | 18.0-20.0 | 11.0 14.0 | 2.00 max | 3.0 4.0 | – |
| 304 | 0.030 max | 0.08 max | 0.75 max | 0.045 max | 18.0-20.0 | 8.0 11.0 | 2.00 max | – | – |
| 310 S | 0.030 max | 0.08 max | 1.5 max | 0.045 max | 24.0-26.0 | 19.0 22.0 | 2.00 max | 3.0 4.0 | – |
| 347 H | 0.030 max | 0.04 0.10 | 0.75 max | 0.045 max | 17.0- 19.0 | 9.0 13.0 | 2.00 max | – | 10C(Cb+Ta)<1.10% |
| 321 | 0.030 max | 0.08 | 0.75 max | 0.045 max | 17.0-20.0 | 9.0 12.0 | 2.00 max | – | 5C 0.70% |
| Grade | Tensile Strength | Yield Strength (0.2%Offset) | Density | Elongation | Melting Point |
|---|---|---|---|---|---|
| SS 303 | Psi – 85,000 | Psi – 45,000 | 55% | 50 % | Rb 180 |
| SS 202 | 515 MPa | 275 MPa | 8.0 g/cm3 | 40 % | 1454 °C |
| SS 304 | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 8.0 g/cm3 | 40% | 1400 °C |
| SS 304L | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 8.0 g/cm3 | 40% | 1400 °C |
| SS 316 | Psi – 75000 , MPa – 515 | Psi – 30000 , MPa – 205 | 8.0 g/cm3 | 35 % | 1454 °C |
| SS 316L | 485 Min | 170 Min. | 8.0 g/cm3 | 40 % | 1400 °C |
| Type | Peeled nd Ground | Cold Drawn and Polish | Peeled and Polished | Cold Drawn and Ground |
|---|---|---|---|---|
| Sizes (mm) | 20.00 – 50.00 | 3.00 to 75.00 | 40.00 – 150.00 | 10.00 to 75.00 |
| Sizes (inch) | 3/4 – 2.00 | 1/8 to3.00 | 1.50 – 6.00 | 5/6 to 2.50 |
| Tolerance | h9 to h11 | h8 to h11 | h11, h11-DIN 1013 | h8 to h11 |
| CD | CF | CG | BD | ST | P&T |
|---|---|---|---|---|---|
| Cold drawn | Cold finished | Centreless ground | Bright drawn | Smooth turned | Peeled and turned |
| P | HRAP | HF | SRE | PR | RT |
| Polished | Hot rolled annealed and pickled | Hot finished | Slit rolled edge | Peeled and reeled | Rough turned/peeled |
The typical lifespan of stainless steel forged bars varies based on usage, environment, and maintenance but generally lasts 20 to 50 years, with proper care, especially in corrosion-resistant conditions.
Yes, stainless steel forged bars and rods can be customized in size, including diameter, length, and shape, to meet specific requirements for various applications in industries like manufacturing and construction.
Stainless steel forged bars are considered environmentally friendly due to their recyclability, durability, and resistance to corrosion. They have a long lifespan, reducing the need for frequent replacements and minimizing waste.
Stainless steel forged bars and rods are widely used where high strength, reliability, and corrosion resistance are critical, especially in heavily loaded or cyclically stressed components. Key applications include shafts, pump and valve parts, gear blanks, flanges, fittings, and connecting elements in sectors such as oil and gas, petrochemical, power generation, marine, construction, and heavy engineering. Their forged structure and stainless chemistry make them suitable for aggressive environments, elevated temperatures, and critical rotating or pressure‑containing duties, helping extend service life and reduce downtime in demanding plants and infrastructure.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
