Sabra Metals is a leading manufacturer and supplier of premium Super Duplex Steel Bars and Rods based in the Ammans, Jordan. Known for our exceptional strength, excellent corrosion resistance, and outstanding performance in harsh environments, our super duplex steel products are ideal for applications in oil and gas, marine, chemical processes, etc. Through our commitment to quality and accuracy, we manufacture super duplex steel bars and rods to ensure the highest standards, in order to meet the needs of our customers We offer solutions bespoke offers, all backed by reliable delivery and exceptional customer service.
Super Duplex steel bars and rods are composed of a high alloy of stainless steel, typically containing 20-30% chromium, 4-7% nickel and 3-5% molybdenum, the rest being steel This product mainly has chloride areas of pitting, cracks corrosion, stress -Provides excellent corrosion and cracking resistance. Technical properties include high tensile strength (up to 800 MPa), excellent toughness, and resistance to high thermal fatigue and oxidation These rods and rods are ideal for use in harsh environments such as offshore, chemical processing, and marine industries. Their advantages include durability, high strength and excellent corrosion resistance.
Specifications : ASTM A276, ASME SA276
Standard : ASTM, ASME
Size : 6 mm to 120 mm.
Length : 1 to 6 Meters, Custom Cut Lengths
Dimensions : EN, DIN, JIS, ASTM, BS, ASME, AISI
| Grade | C | Mn | Si | P | S | Cr | Mo | Ni | N | Fe |
| S32750 | 0.030 max | 1.20 max | 0.80 max | 0.035 max | 0.020 max | 24.00 – 26.00 | 3.00 – 5.00 | 6.00 – 8.00 | 0.24 – 0.32 | 58.095 min |
| S32760 | 0.05 max | 1.00 max | 1.00 max | 0.030 max | 0.010 max | 24.00 – 26.00 | 3.00 – 4.00 | 6.00 – 8.00 | 0.20 – 0.30 | 57.61 min |
| Element | S32760 |
| 0.2% Proof Stress (N/mm2 ) [ksi] minimum | 550 [79.8] |
| Ultimate Tensile Strength (N/mm2) [ksi] minimum | 750 [108.8] |
| Elongation (%) minimum | 25 |
| Reduction of Cross Section Area (%) minimum | 45 |
| Hardness (HBN) | 270max |
| STANDARD | WERKSTOFF NR. | UNS |
| Super Duplex S32750/S32760 | 1.4410 | S32750 / S32760 |
Super Duplex Steel rods are generally resistant to galvanic corrosion due to their high chromium and molybdenum content. However, they can still be susceptible when coupled with highly dissimilar metals in certain environments.
Yes, Super Duplex Steel bars can be welded using appropriate techniques and filler materials. Careful control of heat input and post-weld heat treatment is essential to avoid degradation of their mechanical properties.
Super Duplex Steel rods are available in various sizes, ranging from small diameters to large rods, typically up to 300mm or more. Finishes can include hot-rolled, cold-drawn, polished, or ground, depending on the application requirements.
Super Duplex Steel Bars and Rods are widely used in applications requiring exceptional corrosion resistance, high strength, stress resistance corrosion resistance cracking and are commonly used in chemical processing, oil and in gas, marine and energy production. These materials are resistant to pitting, crack corrosion and fatigue ideal for applications such as heat exchangers, pressure vessels, pipelines, offshore platforms etc. Their superior mechanical properties and versatility make them suitable for harsh environments where both strength and durability are important, ensuring longevity and reliable use in complex industrial applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
