Sabra Metals is a renowned manufacturer and supplier based in Amman Jordan, manufacturing high quality steel products for various industrial applications We are proud to offer Super Duplex Steel Zeron 100 Bars and Rods, which have excellent corrosion resistance, high strength, and are known for exceptional durability. These high-quality products are ideal for harsh environments such as offshore chemicals and marine industries. With our commitment to excellence, Sabra Metals ensures the delivery of Zeron 100 bar and rods. We manufacture them accurately and deliver them quickly, providing our customers with a reliable solution for the most demanding projects.
The Super Duplex Steel Zeron 100 bar end rod is a special blend of about 25% chromium, 7% nickel, 4% molybdenum and nitrogen, for superior corrosion resistance, especially high tensile strength (up to 1000 MPa) in its mechanical properties against chloride-a provides no stress damage cracking ), excellent impact toughness, Includes pitting and crack corrosion resistance The combination of austenitic and ferritic phases increases local corrosion resistance. Zeron 100 bars and rods are ideal for harsh environments such as offshore oil and gas, chemical processing and marine applications, providing high durability, reliability and performance.
| Specifications | ASTM A276, A479, ASTM A182 / ASME SA276, SA479, SA182 |
|---|---|
| Grade | Super Duplex Steel UNS S32760 F55 |
| Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Technique | uns S32760 Cold Drawn, Hot Rolled, Forged Round Bar, Rod, Cold Rolled |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Round bar size | Diameter: 3-~800mm |
| Hex Bar size | 2-100mm A/F |
| Width: 10 to 500mm | |
| Square bar size | 4 to 100mm |
| Flat bar size | Thickness: 2 -100mm |
| Billet Size | 1/2″ to 495mm Diameter |
| Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Section | 3.0 to 12.0mm thickness |
| Form | Precision Ground Bar, Flat Bar, Square, Round, Half Round Bar, Rod, Rectangle, Hex (A/F), T-Bar, Channel Bar,Blocks, Round Rod, Threaded, Profiles, Billet, Ingot, I/H Bar, Forging, Rings, Hollow, Triangle etc. |
| Rectangles Size | 33 x 30mm to 295 x 1066mm |
| Surface | Cold Drawn, Bright, Sand Blasting Finished, Hot Rolled Pickled, Hairline, Polished |
| Processing | Bar cutting to 650mm |
| Certificates | EN 10204 / 3.1 |
| Condition | Hardened & tempered, annealed |
| Our uns S32750 Round bar conforms to NACE MR0175/ISO 15156 | |
| Grade | Cr | Ni | Mo | C | W | Cu | N | Mn | Si | P | S | Fe |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Zeron 100 | 24.0-26.0 | 6.0-8.0 | 3.0-4.0 | 0.030 Max | 0.5-1.0 | 0.50-1.0 | 0.2-0.3 | 1.00 Max | 1.0 Max | 0.03 Max | 0.01 Max | Balance |
| Grades | Alloy Zeron 100 Tensile Strength, ksi | .2% Yield Strength, ksi | % Elongation in 50mm | Hardness Max. |
|---|---|---|---|---|
| Zeron 100 | 109 | 80 | 25 | 28 HRC |
| STANDARD | WERKSTOFF NR. | UNS |
|---|---|---|
| Zeron 100 | 1.4501 | S32760 |
Yes, Super Duplex Steel Zeron 100 bars can be welded. However, proper welding procedures and pre-heat treatments are essential to avoid issues like cracking and maintain its high strength and corrosion resistance.
Super Duplex Steel Zeron 100 rods are highly resistant to galvanic corrosion due to their exceptional corrosion resistance properties. However, if exposed to more active metals in a corrosive environment, some risk of galvanic corrosion may still exist.
Super Duplex Steel Zeron 100 rods are available in a range of diameters, typically from 10 mm to 300 mm, and can be customized based on specific requirements. They are commonly offered in finishes like hot-rolled, cold-rolled, and bright polished.
The wide use of Super Duplex Steel Zeron 100 bars and rods is witnessed in industries that require exceptional corrosion resistance and high strength. They are used in many applications, especially in severe environments, such as in the offshore oil and gas field and chemical processing, marine, etc. They are the best for pitting and crevice corrosion resistance, stress corrosion cracking, in heat exchangers, pipelines, pumps, valves, and pressure vessels. Its outstanding resistance to both chlorides and sour gas environments has qualified the material for demanding applications in power generation, desalination plants, and petrochemical refineries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
