Based in Amman, Jordan, Sabra Metals is a reliable manufacturer and supplier known for its top-notch Stainless Steel 317 Square Bars and Rods, designed for tough, corrosive environments. Crafted from molybdenum-rich austenitic stainless steel, these square bars excel in resisting pitting and crevice corrosion, far surpassing standard grades. Sabra Metals is committed to maintaining rigorous quality control over chemical composition, dimensional accuracy, and surface finish, ensuring that their products consistently perform at a high level. With state-of-the-art production facilities and adaptable supply capabilities, they cater to industries like chemical processing, oil and gas, marine, and heavy engineering around the globe.
The Stainless Steel 317 Square Bars and Rods are made up of chromium (18–20%), nickel (11–15%), and a higher molybdenum content (3–4%), which boosts their resistance to harsh chemical environments. This specific alloy composition not only enhances strength but also improves corrosion resistance. On the mechanical side, SS 317 boasts impressive tensile strength, excellent ductility, and high toughness. It maintains stable mechanical properties even under stress and high temperatures, along with good weldability and formability, making it a great choice for demanding industrial applications.
Stainless Steel 317 Square Bars Specification :
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A582, A276, A564, ASTM A484, 484M
Surface : hrap, hot rolled pickled or sand blasting finished, cold drawn, polished, hairline
Size : Tolerance: H8, H9, H10, H11, H12, H13K9, K10, K11, K12
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 317 | 0.08 max. | 18.0 – 20.0 | 2.00 max. | 11.0 – 14.0 | 0.045 max. | 0.03 max. | 1.00 max. |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.0 g/cm3 | 1400 °C (2550 °F) | Psi ” 75000, MPa ” 515 | Psi ” 30000, MPa ” 205 | 35 % |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 317 | 1.4449 | S31700 |
| SQUARES | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.62 | 2.05 |
| 18 | 0.79 | 2.59 |
| 20 | 0.76 | 2.49 |
| 22 | 1.18 | 3.87 |
| 25 | 1.52 | 5.00 |
| 28 | 1.91 | 6.27 |
| 30 | 2.19 | 7.20 |
| 32 | 2.50 | 8.19 |
| 36 | 3.16 | 10.37 |
| 38 | 3.52 | 11.55 |
| 40 | 3.90 | 12.80 |
| 45 | 4.94 | 16.20 |
| 50 | 6.10 | 20.00 |
| 56 | 7.65 | 25.08 |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Yes, Stainless Steel 317 square bars can be welded using conventional welding methods. However, pre-heating and post-weld heat treatment may be required to avoid cracking.
Yes, Stainless Steel 317 square rods can be heat-treated, typically through solution annealing. However, they are not hardenable by heat treatment like some other stainless steels.
Stainless Steel 317 Square Bars offer excellent corrosion resistance, particularly against chlorides and acids, along with high strength and durability. They are widely used in chemical, petrochemical, and food processing industries.
Stainless Steel 317 Square Bars and Rods are popular in applications that demand high corrosion resistance and mechanical reliability. You’ll find them in structural components, shafts, fasteners, pump and valve parts, and various fabricated assemblies. They’re extensively utilized in chemical processing plants, petrochemical units, oil and gas operations, marine settings, and power generation facilities. Additionally, SS 317 square bars are ideal for pressure equipment, heat exchangers, and engineering components that face harsh chemicals and chloride-rich conditions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
