Sabra Metals is a reputable manufacturer and supplier located in Amman, Jordan, focusing on top-notch stainless steel products tailored for a variety of industrial uses. One of our standout offerings is the Stainless Steel 347 Flat Bar, crafted with precision and rigorous quality checks to align with international standards. Renowned for its reliability and durability, this flat bar is engineered to excel in tough environments. Sabra Metals caters to the construction, petrochemical, power, and fabrication sectors by providing stainless steel solutions that guarantee strength, resistance to corrosion, and a long lifespan.
The Stainless Steel 347 Flat Bar is an austenitic stainless steel alloy that’s stabilized with niobium to reduce carbide precipitation when exposed to high temperatures. Its chemical makeup features chromium and nickel, which contribute to its impressive corrosion resistance, while niobium enhances its thermal stability. On the mechanical side, it boasts good tensile and yield strength, remarkable toughness, and excellent creep resistance. This material retains its mechanical properties even at elevated temperatures, offers good weldability, and stands up to intergranular corrosion in harsh operating conditions.
Stainless Steel 321H Square Bars Specification :
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A582, A276, A564, ASTM A484, 484M
Surface : hrap, hot rolled pickled or sand blasting finished, cold drawn, polished, hairline
Size : Tolerance: H8, H9, H10, H11, H12, H13K9, K10, K11, K12
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 321H | 0.04 – 0.10 | 17.0 – 19.0 | 2.00 max. | 9.0-12.0 | 0.045 max. | 0.03 max. | 0.75 max. |
| Grade | Tensile Str (MPa) min | Yield Str 0.2% Proof (MPa) min | Elong (% in 50mm) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| 321H | 515 | 205 | 40 | 95 | 217 |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 321H | 1.4438 | S32109 |
| SQUARES | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.62 | 2.05 |
| 18 | 0.79 | 2.59 |
| 20 | 0.76 | 2.49 |
| 22 | 1.18 | 3.87 |
| 25 | 1.52 | 5.00 |
| 28 | 1.91 | 6.27 |
| 30 | 2.19 | 7.20 |
| 32 | 2.50 | 8.19 |
| 36 | 3.16 | 10.37 |
| 38 | 3.52 | 11.55 |
| 40 | 3.90 | 12.80 |
| 45 | 4.94 | 16.20 |
| 50 | 6.10 | 20.00 |
| 56 | 7.65 | 25.08 |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Yes, Stainless Steel 321H Square Bars are highly corrosion-resistant due to the addition of titanium, which helps prevent sensitization in high-temperature environments. They are ideal for applications in corrosive environments, offering excellent durability.
Stainless Steel 321H Square Rods offer excellent resistance to high-temperature oxidation, excellent weldability, and exceptional strength at elevated temperatures. They are ideal for applications in the chemical, petrochemical, and power generation industries.
Yes, Stainless Steel 321H Square Bars can be customized in size and length to meet specific requirements. Customization options are available based on customer needs for various applications.
The Stainless Steel 347 Flat Bar is commonly utilized in scenarios that demand high strength along with heat and corrosion resistance. Typical applications include petrochemical equipment, heat exchangers, boilers, pressure vessels, and exhaust manifolds. It’s also frequently found in power generation plants, refineries, and chemical processing facilities that experience continuous thermal cycling. In the realms of fabrication and construction, these flat bars serve as structural supports, frames, and components where long-lasting durability and dependable performance are crucial.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
