Sabra Metals, based in Amman, Jordan, is a trusted manufacturer and supplier of high-quality Stainless Steel 420 bars and rods. Renowned for their excellent hardness, wear resistance, and moderate corrosion resistance, these bars and rods are manufactured to meet stringent industrial standards. Sabra Metals employs advanced production techniques and strict quality control to ensure uniform dimensions, consistent mechanical properties, and reliable performance. Serving industries such as tooling, automotive, aerospace, and machinery manufacturing, the company provides 420 stainless steel bars and rods capable of performing in demanding and precision applications.
Stainless Steel 420 bars and rods are composed of a high-carbon martensitic stainless steel, typically containing 12–14% chromium and 0.15–0.40% carbon. This composition allows the material to achieve high hardness (up to 50–55 HRC after heat treatment), excellent wear resistance, and moderate corrosion resistance. It also offers good machinability, polishability, and dimensional stability, making it ideal for cutting tools, dies, and precision-engineered components.
| Specification | ASTM A276/ A479, ASME SA276/SA479 |
|---|---|
| Grade | Stainless Steel 420 (UNS S42000) |
| Flat bar size | 1/2” to 10” in thickness range of 2mm to 150mm |
| Square bar size | 18mm – 47mm (11/16″ to 1-3/4″) |
| Round bar size | Outside Diameter in the range of 4mm to 500mm |
| Hex Bar size | 18mm – 57mm (11/16″ to 2-3/4″) |
| Bright Bar | Outside Diameter in the range of 4mm to 100mm |
| Channel Bar | 80 x 40mm to 150 x 75mm section; 5.0 to 6.0mm thickness |
| Hollow Bar | 32mm OD x 16mm ID to 250mm OD x 200mm ID) |
| Billet Size | 1/2″ to 495mm Diameter |
| Angle bar size | 3mm*20mm*20mm~12mm*100mm*100mm |
| Rectangular bar Size | 33 x 30mm to 295 x 1066mm |
| Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, Bright, Polish, Grinding, Centreless Ground & Black |
| Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
| Surface | Cold Drawn, Bright, Sand Blasting Finished, Hot Rolled Pickled, Hairline, Polished |
| Condition | Hardened & tempered, annealed |
| Technique | 420 Stainless Steel Cold Drawn, Hot Rolled, Forged Round Bar, Rod, Cold Rolled |
| Processing | Bar cutting to 650mm |
| Section | 3.0 to 12.0mm thickness |
| Form | Precision Ground Bar, Flat Bar, Square, Round, Half Round Bar, Rod, Rectangle, Hex (A/F), T-Bar, Channel Bar,Blocks, Round Rod, Threaded, Profiles, Billet, Ingot, I/H Bar, Forging, Rings, Hollow, Triangle etc. |
| Our 420 Stainless Steel Round bar conforms to NACE MR0175/ISO 15156 | |
| Grade | C | Mn | Si | P | S | Cr | |
| 420 | min. | – | – | – | – | – | 12.0 |
| max. | 0.15 | 1.0 | 1.00 | 0.04 | 0.03 | 14.0 | |
| Grade | Tensile Strength (ksi) min | Elongation (% in 50mm) min | Yield Strength 0.2% Proof (ksi) min | Hardness |
| 420 | 95,000 | 25 | 50,000 | 175 |
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | GOST | AFNOR | EN |
| SS 420 | 1.4021 | S42000 | SUS 420 J1 | 420S29 | – | – | FeMi35Cr20Cu4Mo2 |
Stainless Steel 420 Bars and Rods are known for their excellent hardness, corrosion resistance, and wear resistance. They are a high-carbon steel that can be heat-treated for maximum hardness and are ideal for applications that require strength and durability, such as cutlery, surgical instruments, and valve parts.
Stainless Steel 420 has higher carbon content compared to other grades like 304 or 316, which allows it to be hardened through heat treatment. This makes it particularly suitable for applications that demand high strength, hardness, and wear resistance, although it may not offer the same corrosion resistance as other austenitic grades.
Stainless Steel 420 bars and rods are widely used in knives, cutting tools, molds, dies, bearings, shafts, and other mechanical parts that require high hardness and wear resistance. They are also suitable for tooling, surgical instruments, and automotive components where durability and precision are critical. The combination of mechanical strength, corrosion resistance, and wear resistance ensures reliable performance in demanding applications. Stainless Steel 420 bars and rods are an essential material for industries requiring high-performance, durable, and precision stainless steel solutions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
