Sabra Metals, located in Amman, Jordan, stands out as a leading manufacturer and supplier of top-notch aluminum products, with a focus on precision-forged components. The company has built a reputation for providing reliable, durable, and high-performance aluminum forgings to various industries, including aerospace, automotive, and defense. Thanks to their state-of-the-art production facilities and rigorous quality control measures, Sabra Metals guarantees that each product adheres to international standards. Their deep knowledge in materials engineering allows them to create complex shapes and structural components that boast exceptional mechanical properties, making Sabra Metals a go-to partner for clients in need of superior Aluminium 2017 forgings.
Aluminium 2017 is a robust alloy primarily made up of aluminum, along with copper (3.9–4.9%), magnesium (0.2–0.8%), manganese (0.3–0.9%), and trace amounts of silicon, iron, and zinc. This unique blend offers remarkable fatigue resistance, impressive tensile strength, and decent corrosion resistance when properly treated. The mechanical properties include a tensile strength of about 470–520 MPa, a yield strength of around 330 MPa, and an elongation of 10–15%, with hardness levels ranging from 120 to 140 HB. These traits make Aluminium 2017 forgings perfect for applications that demand durability, high strength, and reliability in tough conditions.
Standards : ASTM B247, B247
Temper : T6 T651 T6511
Specification : DIN, ASTM, BS and all International Standards
Flat bar blocks : up to 27″ width and 15,000 lbs.
Cylinders and sleeves : up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs : up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings : up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts : up to 144″ maximum length and 20,000 lbs.
| Grade | Al | Si | Fe | Cu | Mn | Mg | Cr | Zn | Ti | Others Each | Other Total |
| 2017 | Rem | 0.20-0.8 | 0.7 max | 3.5-4.5 | 0.40-1.0 | 0.40-0.8 | 0.10 max | 0.25 max | 0.15 max | 0.05 max | 0.15 max |
| Material | Condition | Tensile Strength (N/mm²) min | Yield Strength | Elongation in 4D % | ||
| ksi | Mpa | ksi | Mpa | |||
| 2017 | 2017-T4 Bar | 55 | 379 | 32 | 221 | 12 |
| European Standard | OLD | WNr | UNS | ISO | USA (AA) | GERMANY (DIN) |
| AW-AlCu4MgSi | AU4G | 3.1325 | A92017 | AlCu4MgSi | 2017 | AlCuMg1 |
Aluminum 2017 is suitable for forging but has limited high-temperature resistance. For high-temperature forging applications, consider alloys with better heat resistance, like 2219 or 2618.
Aluminum 2017 offers high strength, excellent machinability, good corrosion resistance, and ease of welding, making it ideal for custom forgings in aerospace, military, and high-performance applications.
Aluminium 2017 forgings are extensively utilized in the aerospace and aviation sectors for critical structural components like aircraft frames, wings, and landing gear, thanks to their high strength and fatigue resistance. They also play a vital role in defense applications, such as armored vehicles and military equipment, where performance under pressure is crucial. Furthermore, Aluminium 2017 forgings are found in automotive, marine, and high-performance engineering fields for structural parts and precision components. Their blend of strength, machinability, and lightweight properties makes them an excellent choice for demanding applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
