Sabra Metals, located in Amman, Jordan, stands out as a top-notch manufacturer and supplier of premium aluminum products, with a focus on precision-forged components. They provide robust and corrosion-resistant aluminum forgings for various industries, including marine, automotive, and industrial sectors. Thanks to their state-of-the-art production facilities and rigorous quality control measures, Sabra Metals guarantees that each product adheres to international standards. Their deep knowledge in material engineering enables them to create intricate shapes and high-performance components, making them a trusted partner for clients in need of high-quality Aluminium 5052 forgings.
Aluminum 5052 forgings have a chemical composition of 2.2% to 2.8% MagnesiuAluminium 5052 is a non-heat-treatable alloy that mainly consists of aluminum and magnesium (2.2–2.8%), along with trace amounts of chromium (0.15–0.35%). This composition gives it remarkable corrosion resistance, especially in marine and challenging environments. Its mechanical properties include a tensile strength of about 210–260 MPa, yield strength ranging from 80–200 MPa, and elongation between 12–25%, depending on the temper. It boasts good formability, moderate hardness, and exceptional weldability, making Aluminium 5052 forgings perfect for applications that demand lightweight, strong, and corrosion-resistant components. m, 0.15% to 0.35% Chromium, 0.25% max Zinc, 0.1% max Copper, 0.4% max Silicon, 0.4% max Iron, and Aluminum being the balance. This alloy is characterized by high anti-corrosion properties, especially in marine environments, and good weldability. Mechanically, its tensile strength ranges from 215 to 290 MPa, with yield strengths around 130 MPa elongation depending on forging conditions; it extends evenly from 12-20%. Besides the property of good fatigue resistance, it has moderate strength, making it suitable for the construction of structures, pressure vessels, as well as the manufacturing of products, automotive components requiring high durability and resilience.
Standards : ASTM B247, B247
Temper : H14
Specification : DIN, ASTM, BS and all International Standards
Flat bar blocks : up to 27″ width and 15,000 lbs.
Cylinders and sleeves : up to 50″ maximum O.D. and 65″ maximum length
Discs and hubs : up to 50″ diameter and 20,000 lbs.
Rolled, hand forged or mandrel forged rings : up to 84″ maximum O.D. and 40″ maximum length
Rounds, shafts and step shafts : up to 144″ maximum length and 20,000 lbs.
| Aluminium 5052 | Fe | Si | Mg | Mn | Cu | Zn | Ti | Al |
| 0.15 – 0.40 | 0.10 – 0.25 | 2.20 – 2.80 | 0.01 – 0.10 | 0.01 – 0.10 | 0.01 – 0.10 | 0.020 – 0.030 | 97.2 |
| Alloy | Temper | UTS(Mpa) | % Elongation | |||
| Min | Max | 0.5 mm -0.8 mm | 0.81 mm – 1.30 mm | 1.30 mm – above | ||
| 5052 | O | 171 | 213 | 16 | 18 | 19 |
| H12 | 213 | 261 | 5 | 7 | 9 | |
| H14 | 233 | 281 | 4 | 6 | 7 | |
| H16 | 254 | 302 | 3 | 4 | 4 | |
| H18 | 268 | – | 3 | 4 | 4 | |
| STANDARD | UNS | WERKSTOFF NR. | European Standard | BS (OLD) | ISO | USA (AA) | GERMANY (DIN) |
| Aluminium 5052 | A95052 | 3.3523 | AW-AlMg2,5 | AG2,5C | AlMg2,5 | 5052 | AlMg2,5 |
Aluminum 5052 offers excellent corrosion resistance, high strength, good weldability, and formability. It's lightweight, durable, resistant to stress cracking, and performs well in marine and industrial environments, making it ideal for custom forgings.
Aluminum 5052 is not ideal for high-temperature forging applications due to its relatively low melting point and poor high-temperature strength. Alloys like 7075 or 2011 are better suited for such applications.
You’ll find Aluminium 5052 forgings commonly used in marine and shipbuilding projects, such as hulls, decks, and various marine structures, thanks to their impressive resistance to seawater corrosion. They’re also utilized in the automotive and transportation sectors for fuel tanks, panels, and structural parts where strength and durability are crucial. Moreover, this alloy finds its place in pressure vessels, piping systems, and industrial equipment that face corrosive environments. Its blend of high corrosion resistance, formability, and weldability makes Aluminium 5052 forgings incredibly versatile for demanding applications.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
