Nestled in the industrial heart of Amman, Sabra Metals has built a reputation as a trusted source for high-performance alloys, with a particular focus on precision-engineered Stainless Steel 15-5 PH Hex Bar and Rod. We understand that our clients require materials that offer not just strength, but reliability in demanding environments. This commitment to quality ensures that every bar and rod we supply from our Jordan facility meets the exacting standards needed for critical applications, providing a dependable foundation for industries that cannot afford compromises.
The strength of 15-5 PH stainless steel comes from its precise composition, primarily chromium and nickel, with a key addition of copper. What truly sets it apart is its precipitation-hardening (PH) treatment, a specialized heat process that transforms it into an incredibly strong and tough material. This results in exceptional mechanical properties, including very high tensile strength and impressive corrosion resistance, all while maintaining good toughness. This combination makes it a superior choice where standard stainless steels would fall short.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Grade | C | Cb+Ta | Cr | Cu | Fe | Mn | Ni | P | S | Si |
| SS 15-5 PH | 0.07 max | 0.15-0.45 max | 14.0-15.0 max | 2.5-4.5 max | Bal | 1.0 | 3.5-5.5 | 0.04 | 0.03 | 1.0 |
| Grade | Tensile Strength ksi (MPa) | Yield Strength 0.2% ksi (min) | Elongation % | Hardness (Rockwell) MAX |
| SS 15-5 PH | 161,000 | 140,000 | 7.6% | C35 |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 15-5PH | 1.4545 | S15500 |
| HEXAGONS | ||
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Store Stainless Steel 15-5 PH hex bars and rods in a clean, dry, ventilated area, elevated on racks, with protective covers, separated from other metals, and handled carefully.
Stainless Steel 15-5 PH hex bars excel in wear-resistant applications due to their high strength, toughness, excellent corrosion resistance, and ability to maintain hardness after precipitation-hardening heat treatment.
Common challenges with Stainless Steel 15-5 PH hex bars include susceptibility to stress corrosion cracking in chloride environments, limited ductility in hardened conditions, higher machining difficulty, and potential distortion during heat treatment.
The unique blend of strength and corrosion resistance in our 15-5 PH hex bars and rods makes them indispensable across a wide spectrum of industries. You’ll often find them machined into vital components for aerospace landing gear, or forming the backbone of robust pumps and valves in the oil and gas sector. They are also a preferred material for medical instruments, chemical processing equipment, and high-stress marine components, where their durability ensures long-term performance and safety in challenging conditions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
