Sabra Metals, located in Amman, Jordan, stands out as a top manufacturer and supplier of premium Stainless Steel 446 hex bars. These bars are celebrated for their remarkable high-temperature strength, resistance to corrosion, and overall durability, all crafted to meet strict industrial standards. With cutting-edge production methods and thorough quality checks, Sabra Metals guarantees uniform dimensions, consistent mechanical properties, and dependable performance. The company caters to various sectors, including petrochemical, power generation, chemical processing, and marine, offering 446 stainless steel hex bars that can endure tough and demanding conditions.
The composition of Stainless Steel 446 hex bars features high-chromium ferritic stainless steel, typically containing 23-27% chromium, 0.25% carbon, along with small amounts of nickel and molybdenum. This blend provides outstanding resistance to oxidation and scaling at high temperatures, coupled with impressive tensile strength and good ductility. 446 stainless steel also holds up well against corrosion in mildly aggressive chemical environments and seawater, making it ideal for both high-temperature and outdoor uses.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Specifications
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 446 | 0.2 | 23.00 | 1.5 | 0.50 | 0.040 | 0.030 | 0.75 |
| Element | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness (Brinell (HB) max) |
| SS 446 | Psi – 75,000 , MPa – 485 | Psi – 40,000 , MPa – 275 | 20 % | – |
| HEXAGONS | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
SS 446 Hex Bars offer excellent corrosion resistance, high strength, and durability, making them ideal for harsh industrial environments. Their resistance to oxidation and high-temperature stability ensure reliability in applications like heat exchangers, chemical processing, and petrochemical industries.
SS 446 Hex Bar has superior high-temperature strength and excellent resistance to oxidation compared to other stainless steel alloys like SS 304 or SS 316. Its enhanced durability and corrosion resistance make it ideal for high-stress environments, such as heat exchangers, where other alloys may degrade or weaken over time.
Common machining techniques for SS 446 Hex Bars include turning, milling, drilling, and grinding. Challenges include its high hardness and tendency to work-harden, which can lead to tool wear. Proper lubrication and slower cutting speeds are necessary to maintain tool life and achieve smooth, accurate finishes.
These hex bars find extensive application in high-temperature components, furnace parts, heat exchangers, fasteners, shafts, and structural elements that face corrosive or oxidizing conditions. Their unique combination of heat resistance, mechanical strength, and corrosion protection ensures they perform reliably even in extreme temperatures and chemical exposure. For industries that demand durable, high-performance, and corrosion-resistant stainless steel solutions, 446 hex bars are an indispensable choice.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
