Based in Amman, Jordan, Sabra Metals is a reputable manufacturer and supplier known for its top-notch Stainless Steel 17-7 PH Hex Bars and Rods, perfect for high-strength and spring-tempered applications. Crafted from precipitation-hardening stainless steel, these hex bars boast impressive mechanical strength, excellent corrosion resistance, and outstanding fatigue performance. Sabra Metals takes pride in its meticulous control over chemical composition, heat treatment, and dimensional accuracy, ensuring they meet international standards. With state-of-the-art manufacturing facilities and dependable supply capabilities, the company caters to industries like aerospace, automotive, industrial machinery, and precision engineering around the globe.
The Stainless Steel 17-7 PH Hex Bars and Rods are made up of chromium (16–18%), nickel (6–8%), aluminum (0.75–1.5%), and a carefully controlled carbon content for effective precipitation hardening. This specific blend allows for significant strengthening through heat treatment. In terms of mechanical properties, SS 17-7 PH delivers very high tensile strength, excellent fatigue resistance, and solid toughness. It maintains dimensional stability and reliable performance even under cyclic loading and high-stress conditions, making it an ideal choice for precision and spring applications.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Grade | C | Cb+Ta | Cr | Cu | Fe | Mn | Ni | P | S | Si |
| SS 17-7 PH | .09 | – | 16.0 – 18.0 | – | Bal | 1.0 | 6.50 – 7.75 | .04 | 0.04 | 1.0 max |
| Grade | Tensile Strength ksi (MPa) | Yield Strength 0.2% ksi (min) | Elongation % | Hardness (Rockwell) MAX |
| SS 17-7 PH | 170000 psi | 140000 psi | 6% | 38 |
| STANDARD | WERKSTOFF NR. | UNS |
| SS 17-7 PH | – | S17700 |
| HEXAGONS | ||
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
Common challenges with Stainless Steel 17-7 PH Hex Bar include difficulty in machining due to its hardness, sensitivity to stress corrosion cracking, and the need for precise heat treatment to achieve optimal properties.
Stainless Steel 17-4 PH Hex Bar and Rod should be stored in a dry, clean environment, away from moisture and corrosive substances. Ensure proper ventilation and avoid direct contact with chemicals or humidity.
Yes, Stainless Steel 17-7 PH Hex Bar and Rod are fully recyclable. Stainless steel can be melted down and reused, making it an environmentally friendly material for sustainable manufacturing processes.
Stainless Steel 17-7 PH Hex Bars and Rods find their place in a variety of applications that demand high strength, elasticity, and fatigue resistance. Common uses include springs, fasteners, shafts, fittings, and precision structural components. They are widely utilized in aerospace assemblies, automotive parts, industrial machinery, and electronic equipment. Additionally, SS 17-7 PH hex bars are perfect for components that experience cyclic loading and vibration, where long service life, dimensional accuracy, and mechanical reliability are essential.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
