Located in the heart of Amman, Jordan, Sabra Metals has built a strong reputation as a trusted manufacturer and supplier of high-grade stainless steel products. Among our key offerings is the Stainless Steel 317L Hex Bar and Rod, a premium material chosen for its exceptional performance in demanding environments. We pride ourselves on delivering not just a product, but a reliable solution that meets the precise needs of industries across the region and beyond, ensuring quality and durability from our facility to your project.
The strength of our 317L grade lies in its specific composition, which includes higher levels of chromium, nickel, and, importantly, molybdenum. This enhanced chemistry gives the hex bars and rods superior resistance to corrosion, particularly against chlorides and acids, compared to more common stainless grades. This material maintains excellent mechanical properties, including good tensile strength and ductility, even in high-temperature settings, making it a robust and dependable choice for critical fabrications and structural components.
Dimensions : ASTM, ASME
Standard : ASTM / ASME SA A276, A479, ASTM A493
Length : Random, Fix & Cut Length
Size : 20MM to 150MM
| Element | C | Cr | Mn | Ni | P | S | Si |
| SS 317l | 0.03 max. | 18.0 – 20.0 | 2.00 max. | 11.0 – 14.0 | 0.045 max. | 0.03 max. | 1.00 max. |
| Element | Density | Melting Range,℃ | Tensile Strength | Yield Strength | Elongation | Hardness (Brinell) |
| SS 317l | 8 | 1450 ℃ | 515 | 205 | 40 | 217 |
| HEXAGONS | ||
|---|---|---|
| Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
| 16 | 0.55 | 1.79 |
| 18 | 0.69 | 2.27 |
| 20 | 0.85 | 2.80 |
| 22 | 1.03 | 3.39 |
| 25 | 1.33 | 4.38 |
| 28 | 1.67 | 5.49 |
| 30 | 1.92 | 6.30 |
| 32 | 2.19 | 7.17 |
| 36 | 2.77 | 9.07 |
| 38 | 3.08 | 10.11 |
| 40 | 3.41 | 11.20 |
| 45 | 4.32 | 14.18 |
| 50 | 5.34 | 17.50 |
| 56 | – | – |
| 60 | – | – |
| 65 | – | – |
| 70 | – | – |
| 75 | – | – |
| 80 | – | – |
| 90 | – | – |
| 100 | – | – |
SS 317L Hex Bars/Rods are commonly used in chemical processing, marine environments, pharmaceuticals, and food processing due to their excellent corrosion resistance and high strength. They are ideal for handling aggressive chemicals, including sulfuric acid, bleaching solutions, and pulp liquor. In construction, they are used for structural components and fittings.
SS 317L Hex Bars/Rods typically range from 6 mm to 100 mm in diameter, with lengths up to 6 meters. Tolerances generally conform to ±0.5 mm for diameter. These dimensions and tolerances ensure precision for machining, making them ideal for applications requiring high strength, corrosion resistance, and tight fit.
The high chromium (18-20%) and molybdenum (3-4%) content in SS 317L enhances its resistance to pitting and crevice corrosion by forming a passive oxide layer that protects against chloride-induced degradation. The low carbon content further reduces the risk of stress corrosion cracking, ensuring durability in harsh chloride environments.
Because of its enhanced durability, Stainless Steel 317L Hex Bar and Rod is indispensable in challenging applications. You will often find it forming the backbone of chemical processing equipment, pollution control systems, and components within the pharmaceutical and food industries. Its reliability also makes it a preferred material for architectural features in coastal areas and for fittings in industrial piping that must handle aggressive media, ensuring long-lasting performance where other materials might falter under stress.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
